Specifications
Table 5-3
Specification
Dimensions
Product weight (with max I/O modules)
Power requirements (typical)
Power dissipation (typical)
Operating temperature
Operating humidity
Table 5-4
Media
Port Speed
SMF-IR
155 Mbps or
622 Mbps
SMF-LR 622 Mbps
MMF
155 Mbps or
622 Mbps
Cat. 5
155 Mbps
UTP
75 ohm
44.7 Mbps
coax
75 ohm
44.7 Mbps
coax
75 ohm
34.3 Mbps
coax
Physical specifications
Value
50.2 cm x 7 cm x 38.7 cm
19.75" x 2.75" x 15.25"
4.05 kg
9 lbs
5V, 19 amps at chassis power bus (fully
loaded)
1,008,000 BTU/s (95 watts) (fully loaded)
0 to 40 C (32 to 104 F)
0% to 90% RH, non-condensing
ATM port specifications
Framing
Connector
STS-3 or STM-1
SC
STS-12 or STM-4
STS-12 or STM-4 SC
STS-3 or STM-1
SC
STS-12 or STM-4
STS-3 or STM-1
RJ-45
DS-3
BNC,
nonchannelized
female
DS-3
BNC,
nonchannelized
female
E-3
BNC,
nonchannelized
female
Max. Rx
Max. Tx
Min. Tx
power
Power
power
-8 dBm
-15 dBm
-7 dBm
--
-3 dBm
-7 dBm
-19 dBm -14 dBm
-14 dBm
v
--
--
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
SmartSwitch 9A100 Installation and Setup Guide 5-3
Technical Specifications
Min. Rx
Range
power
-28 dBm
15 Km
-28 dBm
40 Km
-31 dBm
2 Km
--
100 m
n/a
150 m to
DSX
n/a
150 m to
DSX
n/a
150 m to
DSX
