Switch Configuration
Terminal

Figure 3-1 SmartSwitch 9A100 console and network connections

Start the dumb terminal or PC and its terminal emulation software; then turn on the SmartSwitch
5.
9A100 switch.
As the SmartSwitch 9A100 powers up, a series of diagnostic messages appears on the terminal's
6.
screen.
7. After the diagnostics are finished, the switch prompts for a password. Enter the default password,
" ."
admin
The switch prompts for the information necessary to make the switch accessible through your
8.
Ethernet network. Supply the following information:
•
Switch name
3-2 SmartSwitch 9A100 Installation and Setup Guide
Terminal
RJ-45
Port
Configuring the Switch
Ethernet
RJ-45
Port
Ethernet
Network
