User Accessible Components
Figure 2-2 shows the various components that are accessible to the user. These
consist of an eight position dip switch (explained in the next section), replaceable
PROMs and sockets for RAM. These will be used for future upgrades.
Figure 2-2. User Accessible Components
Installing the SmartSwitch 9000 Module
SMB-1 PROM
i960 Processor
Flash SIMM
Socket
DIP Switch
Boot PROM
Shared Packet
Memory SIMM
Local Program Memory
SIMM Socket
2-3
