Installing the SmartSwitch 9000 Module

The Reset Switch

The Reset switch is located on the front panel, under the top plastic tab, as shown
in Figure 2-5. It serves two functions:
• Pressing the reset switch twice within three seconds causes the processor (i960)
to reset.
• Pressing and holding the switch on for three or more seconds causes the
module to shutdown. Pressing and holding again for three seconds restarts the
module.
SNMP management may be used to disable this switch to enhance module
security.
2-8
SMB CPU
Figure 2-5. The Reset Switch
Reset Switch
