- Page 1 SmartSwitch 9000 9C114 and 9C714 Chassis Installation Guide 9031125-03...
- Page 3 Printed in the United States of America Order Number: 9031125-03 LANVIEW is a registered trademark, and SmartSwitch is a trademark of Cabletron Systems, Inc. CompuServe is a registered trademark of CompuServe, Inc. i960 microprocessor is a registered trademark of Intel Corp.
-
Page 4: Fcc Notice
Notice FCC Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. -
Page 5: Declaration Of Conformity Addendum
____________________________________________________ Title Rochester, NH, USA ____________________________________________________ Location Addendum 89/336/EEC 73/23/EEC Cabletron Systems, Inc. 35 Industrial Way PO Box 5005 Rochester, NH 03867 Mr. J. Solari Cabletron Systems Limited Nexus House, Newbury Business Park London Road, Newbury Berkshire RG13 2PZ, England... - Page 6 Notice...
-
Page 7: Table Of Contents
Getting Help ... 1-4 Site Guidelines... 1-5 Installation... 1-5 Required Tools... 1-5 Unpacking the SmartSwitch 9000 Chassis ... 1-5 Installation Order... 1-6 Rack Mounting the Chassis ... 1-7 Installing a Power Supply ... 1-8 Attaching the Electrostatic Discharge (ESD) Wrist Strap... 1-10 Installing the Environmental Module... - Page 8 Contents...
-
Page 9: Chapter 1 Installing The 9Cx14 Chassis
Local Management User’s Guide In addition, each interface module has a user’s guide. The SmartSwitch 9000 The SmartSwitch 9000 chassis is a networking platform that provides support for the configuration and operation of up to 14 Cabletron Systems SmartSwitch 9000 interface modules. -
Page 10: Redundant Power Supply Modules
User’s Guide . The Backplane The 9C114 SmartSwitch 9000 provides six distinct backplane buses, and the 9C714 provides an additional seventh bus, the Cell Transfer Matrix. Each bus serves a particular set of needs. The seven backplane buses are shown in Figure 1-1. - Page 11 The Flexible Network Buses The Flexible Network Buses, FNB-1 and FNB-2, are the primary backplane buses used to connect SmartSwitch 9000 modules for shared network designs. Each FNB bus operates as a dual, counterrotating Fiber Distributed Data Interface (FDDI) ring. Each FNB bus operates at 100 Mbps, and consists of one primary ring and its associated secondary ring.
-
Page 12: Getting Help
• A description of any action(s) already taken to resolve the problem (e.g., changing mode switches, rebooting the unit, etc.) • The serial and revision numbers of all involved Cabletron Systems products in the network • A description of your network environment (layout, cable type, etc.) •... -
Page 13: Site Guidelines
The following guidelines must be followed to select a suitable site for the SmartSwitch 9000. If not, unsatisfactory network performance may result. The site must have an unrestricted free surface area around the SmartSwitch 9000 chassis, allowing for free movement of air. An open space of at least 84 high by 63.5 wide by 81.24 centimeters deep (33 high by 25 wide by 32 inches deep) is the... -
Page 14: Installation Order
Installing the 9Cx14 Chassis Installation Order Once a suitable site has been chosen, the SmartSwitch 9000 may be installed. The unit may be free standing or rack mounted. It is recommended that the SmartSwitch 9000 installation proceed in this order: 1. -
Page 15: Rack Mounting The Chassis
The chassis can be mounted in a standard 19-inch equipment rack. If the rack is not secured to the floor, it is recommended that the SmartSwitch 9000 be installed in the bottom half of the rack. This will prevent the rack from being top heavy. -
Page 16: Installing A Power Supply
Additional power supplies can be added to achieve redundancy. A power supply is installed by plugging it into either the left or right power supply connector on the SmartSwitch 9000 chassis, as shown in Figure 1-3. Install a power supply by following the steps below: 1. - Page 17 STATUS 100% Load 9C214-1 POWER SUPPLY MODULE 100-125v-12A 200-250v-6A 50-60 Hz Figure 1-3. Installing a Power Supply Installing the 9Cx14 Chassis Slot on Chassis Securing Screw Securing Screw...
-
Page 18: Attaching The Electrostatic Discharge (Esd) Wrist Strap
1. Attach one end of the ESD Wrist Strap to your wrist. 2. Plug the other end into the ESD Wrist Strap grounding receptacle in the front lower right corner of the SmartSwitch 9000 chassis, as shown in Figure 1-4. 1-10... -
Page 19: Installing The Environmental Module
Installing the Environmental Module The Environmental Module is installed in the slot above the module card cage in the front of the SmartSwitch 9000 chassis, as shown in Figure 1-5, by following the steps below: 1. Unpack the Environmental Module by carefully removing it from the shipping box and sliding the two foam end caps off of the unit. -
Page 20: Installing Smartswitch 9000 Interface Modules
Figure 1-5. Installing the Environmental Module Installing SmartSwitch 9000 Interface Modules SmartSwitch 9000 Interface Modules can be installed in any of the 14 slots that are available. To install Interface Modules, follow the steps below: 1. Remove the blank panel, covering the slot in which the Interface Module will be installed. - Page 21 Figure 1-6. Check both the upper and lower tracks. 6. If you are installing additional Interface Modules, repeat steps 1–5. Metal Back-Panel Figure 1-6. Installing SmartSwitch 9000 Interface Modules Installing the 9Cx14 Chassis Plastic Locking Tab Plastic Locking Tab...
-
Page 22: Attaching 9C614 Inb Terminator Modules
Attaching 9C614 INB Terminator Modules Two 9C614 INB Terminator Modules must be attached to the rear of the SmartSwitch 9000 chassis when Interface Modules that use the INB are inserted in the front of the chassis. These modules provide proper termination for the Internal Network Bus (INB). -
Page 23: Powering Up The Smartswitch 9000
Figure 1-7. Attaching the INB Terminator Modules Powering up the SmartSwitch 9000 The SmartSwitch 9000 chassis is powered up by following the steps below: 1. Plug one end of the power cord (supplied with the power supply) into the AC power socket on the lower right front corner of the power supply. -
Page 24: Operating Specifications
Installing the 9Cx14 Chassis 5. Check that all LEDs on the INB Terminator Module are green. If the LEDs are any color other than green, refer to the INB Terminator Module Installation Guide . 6. Check that the Status and Alarm LEDs on the Environmental Module are green. -
Page 25: 9C714 Mmac-Plus Chassis
Weight Unit: 19.96 kilograms (44 pounds) Shipping: 24.95 kilograms (55 pounds) 9C714 MMAC-Plus Chassis Dimensions 76.2 H x 48.3 W x 49.3 D centimeters (30 H x 19 W x 19.4 D inches) Weight Unit: 19.96 kilograms (44 pounds) Shipping: 24.95 kilograms (55 pounds) 9C300-1 Environmental Module Dimensions... -
Page 26: 9C614 Inb Terminator Module
Installing the 9Cx14 Chassis 9C614 INB Terminator Module Dimensions 21.59 H x 2.22 W x 14.92 D centimeters (8.5 H x 0.875 W x 5.875 D inches) Weight Unit: 0.45 kilograms (1 pound) Shipping: 0.68 kilograms (1.5 pounds) 1-18...
