TPIM-T2 and TPIM-T4

The TPIM-T2 has an RJ-45 connector supporting an Unshielded Twisted Pair
(UTP) connection. The TPIM-T4 has an RJ-45 connector supporting a Shielded
Twisted Pair (STP) connection. The pinouts for both are listed in Table A-2.
Pin Number
1
2
3
4
5
6
7
8
1 2 3 4 5 6 7 8
Figure A-2. TPIM-T2 and TPIM-T4
Table A-2. TPIM-T2 and TPIM-T4 Pinouts
Ring Out
Represents
Not Used
Not Used
Receive-
Transmit+
Transmit-
Receive+
Not Used
Not Used
LNK
TPIM-T2
Ring In
Pin Number Represents
1
2
3 Transmit-
4
5
6 Transmit+
7
8
TPIM-T2 and TPIM-T4
Not Used
Not Used
Receive+
Receive-
Not Used
Not Used
A-3
