Installing the MicroLAN Modules

User-Accessible Components

Figure 2-3 shows the various components that are accessible to the user. These
consist of an eight position dip switch (explained in the next section), replaceable
PROMs, and sockets for RAM. These will be used for future upgrades.
Instructions for installing the components will be supplied with the upgrade kit.
Local DRAM
Socket
2-4
DIP Switch
Figure 2-3. User-Accessible Components
Boot PROM
SMB-1
PROM
i960
Processor
Shared DRAM
Socket
Flash SIMM
Socket
