See the Cautions at the end of this table.
Switch
8
7
6
5
4
3
2
1
Caution: Do not toggle Switch 8 unless you intend to reset the user configured
passwords to their factory default settings.
!
CAUTION
Caution: Do not toggle Switch 7 unless you intend to reset the user parameters
to the factory default settings.
Table 2-1. Function of DIP Switch
Function
When toggled, this switch clears user-entered
Clear passwords stored in NVRAM, and restores the default
1
passwords. Once reset you can use the defaults or enter
Password
new passwords.
The module uses NVRAM to store user entered
parameters such as IP addresses, device name, etc. To
reset these parameters to the factory defaults, toggle this
Clear
switch. Once reset you can use the defaults or enter new
2
NVRAM
parameters which are stored in NVRAM when the
module is powered down, and remain there until the
switch is toggled again.
Toggling this switch after pulling the board out of the
SmartSwitch 9000, clears download information from
Force BootP
NVRAM and forces image files to be downloaded from
Download
the station configured to act as that modules' BOOTP
server.
For Factory Use Only
Reserved
Reserved For Factory Use Only
Reserved For Factory Use Only
For Factory Use Only
Reserved
Reserved For Factory Use Only
Installing the SmartSwitch 9000 Module
Description
2-5
