Hardware Installation - Enterasys SecureStack C3K122-24 Hardware Installation Manual

Read the Release Notes shipped with the switch to check for any exceptions to the supported
features and operation documented in this guide.
Electrical Hazard: Only qualified personnel should perform installation procedures.
Riesgo Electrico: Solamente personal calificado debe realizar procedimientos de
instalacion.
Elektrischer Gefahrenhinweis: Installationen sollten nur durch ausgebildetes und
qualifiziertes Personal vorgenommen werden.
This chapter provides you with instructions to install your C3K switch. Follow the order of the
sections listed below to correctly install the switch.
For information about...
Installation Prerequisites
Necessary Tools
Unpacking the C3K Switch
Installing the C3K-2XFP Input/Output Module
Installing Mini-GBICs
Installing XFPs
Installing the C3K Switch
Connecting High-Speed Stacking Cables
Configuring Switches in a Stack
Connect AC and RPS Power
Connecting to Console Port for Local Management
Connecting to the Network
Completing the Installation

Hardware Installation

Important Notice
SecureStack C3K Hardware Installation Guide 2-1
2
Refer to page...
2-2
2-2
2-2
2-3
2-5
2-7
2-9
2-13
2-15
2-17
2-19
2-23
2-28
