Installing The Fuselage Servos - Seagull Models SEA232 Assembly Manual

rottle servo.
Epoxy.
e back of fuselage.
THROTTLE SERVO ARM
INSTALLATION.
Install adjustable servo connector in the
servo arm as same as picture below:
Loctite secure.
Adjustable servo
connector.
Rudder berglass control horn.

INSTALLING THE FUSELAGE SERVOS.

Servo arm.
Because the size of servos di er, you
may need to adjust the size of the precut
¡
opening in the mount. e notch in the
Elevator servo arm.
sides of the mount allow the servo lead to
pass through.
1) Install the rubber grommets and brass
collets into all servos. Test t the servos
Rudder servo arm.
into the fuselage servo mounts.
2) Secure the servos with the screws pro-
vided with your radio system.
Elevator servo.
Rudder servo.
rottle servo arm.
Elevator servo.
7
