5.3.8 The SNMP Tools Screen

This section describes specific commands and features within the
SNMP Tools screen. This screen allows you to access management
information bases (MIBs), and varies according to your level of
security access.
The following descriptions outline the super-user management
capabilities. From SNMP Tools you can:
review specifics about object identifiers (OIDs)
edit configurable OIDs
view OIDs sequentially from the originally requested OID.
To access the SNMP Tools Screen from the Features Selection Screen,
use the arrow keys to highlight the SNMP Tool Support option, then
press the Return key. The SNMP Tools Screen, Figure 5-12, appears.
TRXI LOCAL MANAGEMENT
GET
F6
The following describes the SNMP Tools Screen fields and commands.
SNMP TOOLS
COMMUNITY NAME: public
OID PREPEND: 1.3.6.1
SET
GETNEXT
WALK
F7
F8
Figure 5-12. SNMP Tools Screen
LOCAL MANAGEMENT
Flash Image Version: X.XX.XX
RECALL-OID
STEP
CYCLES
F9
RETURN
F10
REPEAT
Page 5-31
