LOCAL MANAGEMENT

5.3.5 The Device Statistics Screen

The Device Statistics screen lets you view ring information, isolating
errors, and non-isolating errors. Figure 5-9 shows the Device Statistics
screen.
TRXI LOCAL MANAGEMENT
INTERFACE: 1
Active Monitor Changes: 0
ISOLATING ERRORS
The following section provides a brief explanation of each field on the
Device Statistics screen and instructions for using them.
Device Statistics
Displays the Device Statistics counter mode. The counter mode lets
you determine how you want the Device Statistics screen to gather
statistics. You can choose the following methods:
• Accumulate: Initiates a new statistic count.
• Delta: Total of statistics beginning from the last screen refresh.
• Total: Total of statistics beginning from the last power-up.
Interface
Displays the network interface. This field is always 1.
Page 5-22
DEVICE STATISTICS (TOTAL)
Frames Received: 0
KBytes Received: 0
Errors Received: 0
Beacon States: 0
Ring Purges: 0
Line Errors: 0
Burst Errors: 0
AC Errors: 0
Abort Transmit Errors: 0
Internal Errors: 0
ACCUMULATE DELTA
Figure 5-9. Device Statistics Screen
Flash Image Version: X.XX.XX
RING INFORMATION
Active Monitor Addr:
Ring Status:
Ring Number:
Stations on Ring:
Ports Enabled:
Ring Speed (Mb/s):
NON-ISOLATING ERRORS
Lost Frame Errors: 0
Frame Copied Errors: 0
Rcvr Congestion Errors: 0
T oken Errors: 0
Frequency Errors: 0
REFRESH99sec
00-00-00-00-00-00
Normal
0
1
24
16
RETURN
