LOCAL MANAGEMENT

5.3.7 The Component Status View Screen

The Component Status View screen is a view only screen that displays
the functions operating in the TRXI.
TRXI LOCAL MANAGEMENT
COMPONENT NAME
Figure 5-11. Component Status View Screen
Setting the Refresh Field
To set the Refresh field:
1. Use the arrow keys to highlight the REFRESH99sec field at the
bottom of the screen.
2. Press the Shift and + keys to increment the time interval or
the - key to decrease the time interval.
3. Press the Return key to save your changes.
Page 5-30
COMPONENT STATUS VIEW
TRXI Chassis MGR
TRXI LIM
Network 1
TRXI Protocol Stack
TRXI SNMP Agent
TRXI RMON
Flash Image Version: X.XX.XX
REFRESH99sec RETURN
