INSTALLATION

3.5 SETTING THE NVRAM SWITCH

Figure 3-7 shows the location of the NVRAM Reset Switch. The TRXI
uses NVRAM (Non-Volatile Random Access Memory) to store user
entered parameters such as IP address and device name. The NVRAM
Reset Switch restores these parameters to the factory defaults.
You do not have to remove the chassis cover to access the NVRAM
switch.
NVRAM RESET
SWITCH
TRXI-24A
TOKEN RING HUB LANVIEW®
WITH
DISPLAY
Figure 3-7. NVRAM Reset Switch
To restore TRXI parameters to the factory defaults:
1. Change the state of this switch (i.e., move the switch from one
position to another).
2. Press the TRXI's Reset button.
You can now use the factory default settings or re-enter your own
parameters. The TRXI stores these parameters in NVRAM during
normal operation and during power down, and they remain there until
you change the switch again.
Caution: Do not change the state of the NVRAM switch unless you
intend to reset the TRXI user parameters to the factory default settings.
Page 3-7
