Table 5-1. System Information Variables
Variable
SerialNo
TftpIpAddress
TftpFilename
PowerUpCount
BroadcastCutoffRate
GatewayIPAddress
TftpStartDownload
BootpDhcpEnable
Reset
Table 5-2. Switch Information Variables
Variable
SwitchIpAddress
SwitchSubnetMask
ActiveAgingTime
SwitchStpStatus
SwitchManager
SwitchTrapRcvr1
SwitchTrapCommunity1
SwitchTrapRcvr2
SwitchTrapCommunity2
SwitchTrapRcvr3
SwitchTrapCommunity3
SwitchTrapRcvr4
SwitchTrapCommunity4
SwitchPortMirroringSta-
tus
9032785
Description
Serial number of the unit.
TFTP server IP address for TFTP downloads.
Filename of the download upgrade file on the TFTP server.
Cumulative number of times switch has powered up or been
reset.
Per second rate past which broadcast and destination un-
known unicast frames are not flooded on each group of 8
ports on the switch.
IP address of the default gateway (router) to which packets
destined for another subnet are sent.
Start TFTP downloads via SNMP, using TftpIpAddress and
TftpFilename.
Enable/disable BootP/DHCP for IP address configuration.
Remotely execute a software reset of the switch.
Description
IP address of the switch, used for management.
Subnet mask corresponding to the SwitchIPAddress.
Aging tick period in seconds by which addresses in the for-
warding table are aged out.
Enable/disable operation of Spanning Tree on the switch.
List of SNMP trap manager IP addresses.
SNMP trap manager IP address #1.
SNMP community associated with trap manager IP address
#1.
SNMP trap manager IP address #2.
SNMP community associated with trap manager IP address
#2.
SNMP trap manager IP address #3.
SNMP community associated with trap manager IP address
#3.
SNMP trap manager IP address #4.
SNMP community associated with trap manager IP address
#4.
Enable/disable port mirroring operation of the switch.
continued on next page
