VLAN Configuration Menu
The VLAN Configuration Menu allows you to configure the operation of
Virtual LANs (VLANs) in the switch. Select c from the Switch
Configuration Menu to view the VLAN Configuration Menu. Figure 3-11
shows the VLAN Configuration Menu and the accompanying table
describes the VLAN Configuration Menu. See Appendix D, "Virtual LANs
(VLANs)" for more information about this feature.
VLAN CONFIGURATION
a. VLAN Enable
b. VLAN Menu
c. VLAN Port Menu
x. Previous Menu
Enter Selection:
Figure 3-11. VLAN Configuration Menu
Selection
VLAN Enable
VLAN Menu
VLAN Port Menu
9032785
No
Description
Allows you to enable (Yes) or disable (No) the global VLAN
operation of the switch.
Allows you to open the VLAN Menu.
Menu for configuring VLAN information per port.
Access Control: READ/WRITE
ELS100-24TXM User Interface 39
