Keyboard Entries

This guide uses the following conventions for keyboard entries:
•
When you read "enter," type the text and press the [Enter] key.
•
Example: Enter the Gateway IP address and press the [Enter] key.
•
When you read "select," type the letter associated with the
parameter.
Example: Select a from the System Configuration Menu to view the
SNMP Configuration Menu.

Other Conventions

This guide uses the following typographical conventions:
•
Initial Caps
•
[Enter]
•
ALL CAPS
•
courier font Screen messages and user prompts.
•
Selection
•
Field

Organization

Chapter 1. Product Overview: Describes the features of the switch, front
and rear panel components and application examples.
Chapter 2. Installation: Describes the content of your switch shipment,
lists site requirements, and provides mounting instructions. Instructions
for making connections and powering up the switch are provided as well.
Chapter 3. ELS100-24TXM User Interface: Describes the user interface
console menus and lists the factory defaults for system settings. Each of
the console menus are presented along with a description of the
selections/fields available within each menu.
Chapter 4. Configuring and Monitoring the Switch: Describes
common tasks and associated steps required to configure the switch, and
covers common switch and network considerations required to ensure
system integrity.
Chapter 5. SNMP Management: Describes how the Simple Network
Management Protocol (SNMP) communication protocol is used to
manage the switch, and provides a description of industry standard and
proprietary Managed Information Bases (MIBs) supported by the switch.
ii Preface
Menu titles and console menu selections
Used to designate the Enter or Return key.
Used to designate fields within the console menus.
(Example: CONNECTION)
Describes a user-configurable user interface item.
Describes a read-only information item
ELS100-24TXM
