Forwarding Table Configuration Menu

The Forwarding Table Configuration Menu allows you to view and modify
forwarding table parameters. The MAC address of each forwarding table
entry is displayed along with its type, disposition, and associated port
number. Select a from the Switch Configuration Menu to view the
Forwarding Table Configuration Menu. Figure 3-7 shows the Forwarding
Table Configuration Menu and the accompanying table describes the
Forwarding Table Configuration Menu.
FORWARDING TABLE CONFIGURATION
MAC ADDRESS
---------------------------------------------------------------------------------------------------------------------
0a0a0a0a0a0b
0a0a0a0a0a0b
0a0a0a0a0a0c
0a0a0a0a0a0d
0a0a0a0a0a0e
0a0a0a0a0a0f
0a0a0a0a0a10
0a0a0a0a0a11
n. Next Page
a. Display Table
c. Add Static Entry
s. Search by Port #
Enter Selection:
Figure 3-7. Forwarding Table Configuration Menu
Field
MAC Address
Type
Disposition
Port ID
Port Name
Selection
Next Page
Previous Page
First Page
Last Page
9032785
TYPE DISPOSITION
DYNAMIC FORWARD
DYNAMIC FORWARD
DYNAMIC FORWARD
DYNAMIC FORWARD
DYNAMIC FORWARD
DYNAMIC FORWARD
DYNAMIC FORWARD
DYNAMIC FORWARD
p. Previous Page f. First Page
b. Make Entry Static
d. Delete Static Entry
m. Search by MAC Address x. Previous Menu
Description
MAC address for the listed port.
Displays the type of address entry: system, dynamic or stat-
ic.
Displays disposition of the address entry: local, forward or
discard.
Displays the port number associated with the MAC address
entry.
Displays the administrative name assigned to the port.
Description
Displays the next page of the forwarding table.
Displays the previous page of the forwarding table.
Displays the first page (top) of the forwarding table.
Displays the last page of the forwarding table.
Access Control: READ/WRITE
PORT ID PORT NAME
1
2
3
4
5
6
7
8
l. Last Page
e. Modify Static Entry
continued on next page
ELS100-24TXM User Interface 33
