Cabletron Systems ESX-1380 Addendum

ESX-1320R/ESX-1380R
ADDENDUM
This addendum in conjunction with the ESX-1320/ESX-1380 Installation Guide
and the ESX-1320/ESX-1380 Local Management Guide provides the
documentation necessary to install and manage the ESX-1320R or the
ESX-1380R Ethernet Workgroup Switch. This addendum documents the
hardware differences between the ESX-1320/ESX-1380 and the
ESX-1320R/ESX-1380R. Refer to the ESX-1320/ESX-1380 Installation Guide
for information concerning installation and troubleshooting. Refer to the
ESX-1320/ESX-1380 Local Management Guide for information on accessing and
using Local Management.

Overview

The ESX-1320R and the ESX-1380R are functionally the same as the ESX-1320
and the ESX-1380, respectively, except the ESX-1320R and the ESX-1380R are
equipped with redundant, load sharing power supplies. If one power supply fails,
the other power supply continues to provide the power necessary to operate the
unit. Two LEDs on the back of the unit (see Figure 1) indicate the operating
status of the two power supplies. To accommodate the addition of the second
internal power supply, the depths of the ESX-1320R and the ESX-1380R are
greater than those or the ESX-1320 and the ESX-1380.
THIS UNIT HAS TWO POWER SUPPLY CORDS. DISCONNECT BOTH
POWER SUPPLY CORDS BEFORE SERVICING TO AVOID ELECTRIC
SHOCK.
DIESES GERÄT HAT MEHR ALS EINEN NETZANSCHLUß. TRENNEN SIE
VOR WARTUNGSARBEITEN DIE 2 NETZANSCHLÜSSE VOM NETZ, UM
ELEKTRISCHE SCHLAGE ZU VERMEIDEN.
CET APPAREIL COMPORTE PLUS D'UN CORDON D'ALIMENTATION.
RAFIN DE PREVENIR LES CHOCS ELECTRIQUES, DEBRANCHER LES 2
CORDONS D'ALIMENTATION AVANT DE FAIRE LE DEPANNAGE.
Figure 1 ESX-1320R or ESX-1380R (Rear View)
PN 9031984-01
Power 2
Power 1
LANVIEW Power
Supply LEDs
Page 1
