Switch Summary Screen

The Switch Summary Screen allows you to display sum total statistics for
all ports of the switch. You can also clear or refresh the statistics. Select
s from the Switch Statistics Screen to view the Switch Summary screen.
Figure 3-20 shows the Switch Summary Screen and the accompanying
table describes the Switch Summary Screen.
SWITCH SUMMARY
Frames Transmitted
Frames Received
Frames Forwarded
Frames Filtered
Frames Dropped
Frames Errored
r. Refresh c. Clear
Enter Selection:
Figure 3-20. Switch Summary Screen
Field
Frames Transmitted
Frames Received
Frames Forwarded
Frames Filtered
Frames Dropped
Frames Errored
Selection
Refresh
Clear
48 ELS100-24TXM User Interface
Access Control: READ/WRITE
0
0
0
0
0
0
x. Previous Menu
Description
Total number of frames transmitted out all ports.
Total number of frames received on all ports.
Total number of frames forwarded through the switch.
Total number of frames filtered on all ports.
Total number of frames dropped by the switch due to lack of
resources.
Total number of errored frames received from all ports.
Description
Refreshes switch summary statistics.
Clears (or sets to zero) switch summary statistics.
