System Configuration Menu

The System Configuration Menu enables modification of system-level
switch configuration parameters. Select a from the Main Menu to view the
System Configuration Menu. Figure 3-4 shows the System Configuration
Menu and the accompanying table describes the System Configuration
Menu.
SYSTEM CONFIGURATION
a. SNMP Configuration Menu
b System Name
c. System Location
d. System Contact
e. IP Address
f. Subnet Mask
g. Default Gateway
h. BootP/DHCP Enable
i. Screen Timeout (minutes)
j. Password
k. Terminal Baud Rate
l. Terminal Hardware Flow Control
x. Previous Menu
Enter Selection:
Figure 3-4. System Configuration Menu
Selection
SNMP Configuration Menu
System Name
System Location
System Contact
IP Address
Subnet Mask
Default Gateway
BootP/DHCP Enable
Screen Timeout (minutes)
Password
Terminal Baud Rate
Terminal Hardware Flow
Control
30 ELS100-24TXM User Interface
Access Control: READ/WRITE
000.000.000.000
000.000.000.000
000.000.000.000
Yes
0
None
9600
No
Description
Menu for configuring SNMP-related parameters.
The switch administrative name (1-36 character range).
The physical switch location (1-36 character range).
The switch contact person (1-36 character range).
The IP address of the switch.
Subnet mask associated with the switch IP address.
The default gateway (or router) to which the switch sends
IP packets destined for a different subnet.
Allows you to enable (Yes) or disable (No) the BootP and
DHCP protocols for automatically configuring the
switch's IP address information.
The duration of time before a serial console or Telnet
session terminates due to user inactivity (0-65535 nu-
meric range). A value of "0" means that the screen will
not terminate at any time.
Allows "read/write" access to the user interface, via the
serial console or Telnet (1-10 character range).
Serial console baud rate (2400, 9600 or 19200).
Allows you to enable (Yes) or disable (No) hardware flow
control on serial console interface. Signals DTR, RTS
and CTS are used for this purpose. Flow control should
be enabled if using external modem.
