Switch Statistics Screen

The Switch Statistics Screen provides a summary display of port-level
statistics, and provides access to the Port Statistics screens. You can also
clear or refresh the statistics. Select d from the Main Menu to view the
Switch Statistics Screen. Figure 3-19 shows the Switch Statistics Screen
and the accompanying table describes the Switch Statistics Screen.
SWITCH STATISTICS
ID TRANSMITTED
---------------------------------------------------------------------------------------------------------------------------
1 0
2 0
3 0
4 0
5 0
6 0
7 0
8 0
9 0
10 0
n. Next Page p. Previous Page
s. Switch Summary
r. Refresh c. Clear
Enter Selection:
Figure 3-19. Switch Statistics Screen
Field
ID
Transmitted
Received
Forwarded
Filtered
Dropped
Errored
Selection
Next Page
Previous Page
First Page
Last Page
Switch Summary
Port Statistics
Refresh
Clear
9032785
RECEIVED FORWARDED FILTERED
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
f. First Page
d. Port Statistics
x. Previous Menu
Description
The number assigned to the port.
Number of frames transmitted out the port.
Number of frames received on the port.
Number of frames forwarded through the port.
Number of frames filtered on the port.
Number of frames received on the port that were dropped by the
switch due to lack of resources.
Number of errored frames received on the port.
Description
Displays the next page of the table.
Displays the previous page of the table.
Displays the first page of the table.
Displays the last page of the table.
Allows you to open the Switch Summary Screen.
Allows you to open the Port Statistics Screen.
Refreshes switch statistics.
Clears (or sets to zero) switch statistics.
Access Control: READ/WRITE
DROPPED ERRORED
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
l. Last Page
ELS100-24TXM User Interface 47
