Port Statistics Screen

The Port Statistics Screen allows you to display statistics for each port on
the switch. Many of these statistics correspond to the Statistics group of
RMON. You can also refresh or clear the statistics. Select s from the
Switch Statistics Screen to view the Port Statistics screen. Figure 3-21
shows the Port Statistics Screen and the accompanying table describes
the Port Statistics Screen.
PORT 1 STATISTICS
Frames Transmitted
Frames Received
Frames Forwarded
Frames Filtered
Frames Dropped
Broadcasts Transmitted
Broadcasts Received
Multicasts Transmitted
Multicasts Received
Bytes Transmitted
Bytes Received
Pause Frames Transmitted
Pause Frames Received
r. Refresh c. Clear
Enter Selection:
Field
Frames Transmitted
Frames Received
Frames Forwarded
Frames Filtered
Frames Dropped
Broadcasts Transmitted
Broadcasts Received
9032785
0 Collisions
0 Late Collisions
0 CRC/Alignment Errors
0 Undersized Frames
0 Oversized Frames
0 Fragments
0 Jabbers
0 64 Byte Frames
0 65 to 127 Byte Frames
0 128 to 255 Byte Frames
0 256 to 511 Byte Frames
0 512 to 1023 Byte Frames
0 1024 to 1518 Byte Frames
x. Previous Menu
Figure 3-21. Port Statistics Screen
Description
Total number of frames transmitted on the port.
Total number of frames received on the port.
Total number of frames received on the port which were
forwarded to other ports.
Total number of frames received on the port which were
filtered.
Total number of frames received on the port which were
dropped by the switch due to lack of resources.
Total number of broadcast frames transmitted on the port.
Total number of broadcast frames received on the port.
Access Control: READ/WRITE
0
0
0
0
0
0
0
0
0
0
0
0
0
continued on next page
ELS100-24TXM User Interface 49
