Spanning Tree Port Configuration Menu

The Spanning Tree Port Configuration Menu allows you to view Spanning
Tree Configuration information for all of the ports in a table format. Select
b from the Spanning Tree Configuration Menu to view the Spanning Tree
Port Configuration Menu. Figure 3-9 shows the Spanning Tree Port
Configuration Menu and the accompanying table describes the Spanning
Tree Port Configuration Menu.
SPANNING TREE PORT CONFIGURATION
PORT ID PORT NAME
---------------------------------------------------------------------------------------------------------
1
2
3
4
5
6
7
8
9
10
n. Next Page
a. Select Port
Enter Selection:
Figure 3-9. Spanning Tree Port Configuration Menu
Field Description
Port ID A unique identifier for a port on the bridge (switch).
Port Name The administrative name assigned to the port.
Path Cost The contribution of the path through this port, when it is the root port,
to the total path cost from this bridge to the root bridge. 10 for 100Mbps
ports, 100 for 10Mbps ports.
Port Priority The relative priority of the port on the bridge.
Port State The current Spanning Tree state of the port on the bridge, either dis-
abled, listening, learning, forwarding, or blocking.
Selection Description
Next Page Displays the next page of the table.
Previous Page Displays the previous page of the table.
First Page Displays the first page (top) of the table.
Last Page Displays the last page of the table.
Select Port Allows you to enter a port number to view and modify port parameters
in the Spanning Tree Port #n Configuration Menu.
9032785
PATH COST PORT PRIORITY
10
10
10
10
10
10
10
10
10
10
p. Previous Page f. First Page
r. Refresh x. Previous Menu
Access Control: READ/WRITE
PORT STATE
128 FORWARDING
128 FORWARDING
128 FORWARDING
128 FORWARDING
128 FORWARDING
128 FORWARDING
128 FORWARDING
128 FORWARDING
128 FORWARDING
128 FORWARDING
l. Last Page
ELS100-24TXM User Interface 37
