Class of Service Configuration Menu

The Class of Service Configuration Menu allows you to configure Class of
Service settings for the system as well as to set the Class of Service for
VLAN tagged frames. Select d from the Switch Configuration Menu to
view the Class of Service Configuration Menu. Figure 3-15 shows the
Class of Service Configuration Menu and the accompanying table
describes the Class of Service Configuration Menu.
CLASS OF SERVICE CONFIGURATION
a. Class of Service Enable
b. Priority Threshold
c. Configure Port Priority
x. Previous Menu
Enter Selection:
Figure 3-15. Class of Service Configuration Menu
Selection
Class of Service
Enable
Priority Threshold
Configure Port Priority
9032785
No
4
Description
Allows you to enable (Yes) or disable (No) Class of Service
operation for the system.
Allows you to enter the global priority threshold level. The
configurable range is 0-7 (0=low, 7=high).
VLAN tagged frames with a priority level below this threshold
level will be assigned normal priority level through the switch.
VLAN tagged frames with a priority level equal to or greater
than this threshold level will be assigned high priority through
the switch.
Allows you to open the Port Priority Menu for configuring
Class of Service information per port.
Access Control: READ/WRITE
ELS100-24TXM User Interface 43
