Setup Antennas (Pitch Antenna)
SEPARATION
LEVEL
SWAP ANTENNAS
SLIP OFFSET
PITCH OFFSET
BACK
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_II_Range/VBOX_II_User_Guide/01_-_VBOX_II_Front_Panel
Press '■' and then use the '◄' and '►' buttons to
change the antenna separation. Then press '■' to
confirm.
Range is 0.5 – 5.0 m in 0.1 m increments
Press'■' and then use the '◄' and '►' buttons to enable
or disable the LEVEL option. With the LEVEL set to YES
the RTK lock is more resilient.
But maximum ROLL or PITCH in this mode should be
10 degrees.
Set to 'ON' to allow the primary Antenna A to be
mounted ahead of the Secondary Antenna B.
Default is 'OFF'. Then press '■' to confirm.
Press '■' to enter the Slip offset sub menu. Within this
sub menu the Slip offset can be calculated and applied
or cleared.
Press '■' to enter the Pitch offset sub menu. Within this
sub menu a Pitch offset can be calculated and applied
or cleared.
Press '■' to go back to the Main menu.
