Racelogic VBOX II User Manual page 59

Connector 5 - CAN (Lemo 5 PIN)
(First CAN Bus Connector, Serial Connection to GPS Engine)
PIN
1
2
3
4
5
Chassis
I/O
O
I
I/O
I/O
I/O
I
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_II_Range/VBOX_II_User_Guide/15_-
Function
RS232 Tx GPS (Tx Data from GPS
engine)
RS232 Rx GPS (Rx Data to GPS
engine)
CAN High
(direct connection between ports 5
and 6)
CAN Low
(direct connection between ports 5
and 6)
Power +
Ground
_VBOX_II_Technical_Properties/VBOX_II_PIN_OUTS
59
