11 - VBOX II Digital and Analogue Outputs
The outputs on connectors OUT1 and OUT2 can be used either as frequency/pulse digital outputs or as analogue
outputs that can be configured to represent any of the following parameters:
• Velocity
• Longitudinal Acceleration
• Lateral Acceleration
• Slip Angle*
• Pitch Angle*
• Roll Angle*
* SL units only
For digital outputs, the scale and maximum output values can be adjusted using the
front panel controls. For velocity, these are controlled by setting the maximum velocity and the pulses per metre. For the
other parameters, the scale and maximum are controlled by setting the maximum frequency and the angle or
acceleration value to which this relates. Please note that the digital outputs do not show the direction of angles and
accelerations, only their magnitudes. Therefore "negative" angles or accelerations will be shown in the same way as
their positive equivalents.
For analogue outputs, the values relating to the maximum voltage (+5V) and minimum voltage (0 for Velocity, –5V for all
other channels) can be set, either via the front panel or using the
of the analogue outputs allows the direction of angles and accelerations to be output.
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_II_Range/VBOX_II_User_Guide/11_-
VBOX Setup Software
VBOX Setup
Software.The negative voltage capability
_VBOX_II_Digital_and_Analogue_Outputs
or via the
