04 - VBOX II VBOX Setup Overview
Introduction
VBOX Setup Software can be used to configure VBOX II units and provides greater functionality in comparison to
using the front panel.
IMPORTANT
- The software is not compatible with VB20SL3 units.
Connection
To configure VBOX II, the VBOX needs to be connected to a power source and a PC.
Configuration can be performed using VBOX Setup software, which can be downloaded here. You can connect to a
computer either via an RLCAB001 cable to the 'SER' input and the computer's serial port (usb-serial adapter may be
required), or via an RLCAB042 cable to one of the computer's USB ports.
IMPORTANT
– Microsoft Windows 7 SP1 or newer is required (must be compatible with .Net Framework 4.7.1)
Once physically connected and powered, open the software and use the drop down list to select the correct COM port
that the VBOX II is connected to. VBOX Setup automatically connects to the selected device and enters the VBOX
II setup screen.
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_II_Range/VBOX_II_User_Guide/04_-
_VBOX_II_VBOX_Setup_Overview
19
