03 - VBOX II Display Screen Overview
The screen will display data when the VB2 is operating. It also displays all the menus required to configure the VB2 via
the front panel controls.
On start-up, the display screen shows the unit's firmware version and current offset value.
During normal operation, the display screen displays Speed (mph or km/h) and Slip Angle (dual antenna units
only) Scroll left or right ( '◄'and '►'), to display Pitch or Roll Angle instead.* As well as the number of satellites that the
VB2 has locked on to, there are also three status indicators at the top of the display.
*Slip, pitch and roll angle only available on dual / triple antenna units.
