18. The maximum allowable ambient temperature of the room where this product will be installed is
104°F (40°C).
19. Suggested list of codes and standards for the United States and Canada -
a. General Installation:
i. - Installation of Air Conditioning and Ventilation Systems NFPA 91 (latest edition).
b. Duct Systems:
i. Sheet Metal and Air Conditioning Contractors National Association (SMACNA)
ii. American Society of Heating, Refrigeration, and Air Conditioning Engineers (ASHRAE)
iii. 2001 Fundamentals Handbook Chapter 34 or 2000 HVAC Systems and Equipment
Handbook Chapters 9 and 16
iv. US and Canada: Air Conditioning Contractors Association (ACCA) Manual D
c. Acoustical Lining and Fibrous Glass Duct:
i. US and Canada: current edition of SMACNA; NFPA 90B as tested by UL Standard 181
for Class 1 Rigid Air Ducts
d. Plumbing Systems:
i. US and Canada: ICC International Plumbing Code (IPC); Uniform Mechanical Code
(UMC); Uniform Plumbing Code (UPC)
6. PRODUCT INFORMATION & SPECIFICATIONS >
syncFURNACE OD is a combined, modulating gas-fired tankless condensing water heater and hydronic fan-
coil unit, designed to provide space heating via warm-air fan-coil and potable water heating on-demand.
Available with an internal add-on to provide whole home DHW re-circulation. It is 100% factory tested
and calibrated.
An advanced internal controller operates both the modulating gas-fired tankless condensing water heater
and hydronic fan-coil unit. The controller monitors and adjusts the combined system to minimize energy
usage during operation.
syncFURNACE OD incorporates a stainless steel, modulating gas-fired tankless condensing water heater
that is factory set for use with Natural Gas (optional factory set propane model is available).
The hydronic fan-coil unit has an internal pump circulates hot water through a water coil heat exchanger.
The hot water coil is built using copper tube and aluminum fins to provide excellent heat exchange. A
blower inside the fan-coil is used to move building air across the coil and distribute heated air back out to
the building. In addition to space warm-air heating, the fan-coil unit can also perform continuous air-
circulation (fan-only) and air-conditioning (air-conditioning coil & condenser sold separately) functions for
the building. The fan-coil unit is available in either low-velocity (low static pressure) or high-velocity (high
static pressure) configuration.
