SMA Solar Technology AG
5.5 Context menu
Menu item
Sunny WebBox registration
Status configuration
Password settings
Sunny Portal settings
Update settings
5.6 Status Page
On the "Status" page, an overview of the current status of the PV plant is given in the upper area.
The following information is shown:
Device status
Operating mode
Setpoint (set)
Setpoint (current)
Status of the input ports
Display of the current status of the Power Reducer Box
The device status is also displayed on the login page of the Power Reducer Box.
User Manual
Function
This menu item opens the "Sunny WebBox registration"
page (see Section 8.2 "Sunny WebBox Registration in the Power
Reducer Box", page 38).
This menu item opens the "Status configuration"
page (see chapter 8.3 "Configuring Operating Modes", page 40).
This menu item opens the "Password settings" page.
This menu item opens the "Sunny Portal settings"
page (see Section 4.4 "Sunny Portal", page 18).
This menu item opens the "Update settings" page (see Section
10.6 "Firmware Update for the Power Reducer Box", page 55).
The device status displays the overall status of the Power Reducer Box.
The operating mode displays the setpoint that the Power Reducer Box
is currently implementing.
The setpoint (target) displays the values that have been configured in
the Power Reducer Box for the parameter.
The setpoint (current) displays the values that are currently being
implemented.
The status shows the current incoming signal from the ripple control
receiver. K1 to K4 relate to the respective connected relays. If no signal
is incoming, the value "Open" is displayed.
5 The Power Reducer Box User Interface
REDUCERBOX-BA-en-16 23
