Summary of Contents for SMA SUNNY BOY 2000HF-US
- Page 1 Accessory for SUNNY BOY 2000HF-US SUNNY BOY 2500HF-US SUNNY BOY 3000HF-US RS485-Quick Module Installation Guide RS485-QM-IA-eng-IUS111610 | IMUS-485QMODULE | Version 1.0...
- Page 3 All such warranties are expressly disclaimed. Neither SMA America, LLC nor its distributors or dealers nor SMA Solar Technology Canada Inc. nor its distributors or dealers shall be liable for any indirect, incidental, or consequential damages under any circumstances.
- Page 4 A warning describes a hazard to equipment or personnel. It calls attention to a procedure or practice, which, if not correctly performed or adhered to, could result in damage to or destruction of part or all of the SMA equipment and/or other equipment connected to the SMA equipment or personal injury. DANGER DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury.
- Page 5 SMA assumes no responsibility for the compliance or noncompliance with such laws or codes in connection with the installation of the inverter. For all repair and maintenance always return the unit to an authorized SMA Service Center.
- Page 6 General Warnings SMA America, LLC RS485-QM-IA-eng-IUS111610 Installation Guide...
-
Page 7: Table Of Contents
SMA America, LLC Table of Contents Table of Contents Information on this Manual......9 Validity ..........9 Target Group . - Page 8 Assembly........19 Open SMA DC-Disconnect......19 Connecting the RS485 Quick Module to the RS485 bus.
-
Page 9: Information On This Manual
Detailed information regarding installation, commissioning, maintenance and troubleshooting can be found in the inverter installation guide. Further information about SMA America, LLC equipment is available in the download section of the www.SMA-America.com website. Among other things, the download area contains the following items: •... -
Page 10: Safety
The RS485-Quick Module is provided as an upgrade kit or included in the scope of delivery of the inverter. The RS485-Quick Module is only suitable for use with SMA inverters of type Sunny Boy 2000HF-US / 2500HF-US / 3000HF-US. Please also observe the installation guide of the respective inverter. -
Page 11: Rs485-Quick Module
RS485-Quick Module 3 RS485-Quick Module The SMA inverters of the SB 2000 HF-US / 2500 HF-US / 3000 HF-US types are equipped with a communication module (Quick Module) and a Bluetooth Wireless Technology interface by default. You can retrofit the inverters with the RS485-Quick Module with an RS485 interface and multifunction relay. -
Page 12: Interior View Of The Rs485 Quick Module
RS485-Quick Module SMA America, LLC 3.3 Interior View of the RS485-Quick Module Object Description Rotary switch for setting the installation country Rotary switch for setting the display language Rotary switch for the configuration of Bluetooth communication Multi-function relay and connection terminal... -
Page 13: Preparations For The Rs485 Quick Module
SMA America, LLC Preparations for the RS485-Quick Module 4 Preparations for the RS485-Quick Module 4.1 Notes When the RS485-Quick Module is delivered, the resistor is located in the left spring-type terminal. If you do not wish to connect the inverter to the end of the RS485 bus, you must remove the resistor, in order to connect two cables. -
Page 14: Configuring The Rs485 Quick Module
Preparations for the RS485-Quick Module SMA America, LLC 4.3 Configuring the RS485-Quick Module 4.3.1 Setting the language and installation country via the rotary switch Configuration of the RS485-Quick Module Before Installation If you have not yet installed the RS485-Quick Module, proceed as follows to set the installation country and the language: 1. - Page 15 Configuration of the RS485-Quick Module After Installation 1. If the multi-function relay is already connected, switch off the multi-function relay power supply. 2. Open SMA DC-Disconnect (see section 5.1 „Open SMA DC-Disconnect.“ (page 19)). 3. Pull the RS485-Quick Module out to the stopper.
-
Page 16: Communication Via Bluetooth
2 ... F Networking with other inverters The NetID helps distinguish PV plants with SMA Bluetooth that are within a proximity of 1640 ft. (500 m) of each other. Detect a free NetID before commissioning your Bluetooth PV plant. This way you will make sure that you will not register any other Bluetooth PV plant in your proximity. - Page 17 SMA America, LLC Preparations for the RS485-Quick Module In order for all inverters in your plant to be detected by your communication device, all inverters must have the same NetID. To assign a NetID, proceed as follows: 1. Using a screwdriver of switch ⁄...
-
Page 18: Terminating The Rs485 Bus
Preparations for the RS485-Quick Module SMA America, LLC 4.4 Terminating the RS485 Bus You must set the termination only on the inverter that is connected to the end of the RS485 bus. When the RS485-Quick Module is delivered, the resistor for termination is located in the left spring-type terminal. -
Page 19: Assembly
5.1 Open SMA DC-Disconnect. WARNING High voltages in the inverter. Death or serious injuries. • Before working on the SMA DC-Disconnect, disconnect the AC switch and make sure it cannot be switched on. • Disconnect the multi-function relay power supply. • Set the DC disconnector of the SMA DC-Disconnect to the "Off" position. -
Page 20: Connecting The Rs485 Quick Module To The Rs485 Bus
• Conductors must be made up of twisted wire pairs. • The cable must be shielded and double insulated. • For outdoor use only: the cable must be UV resistant. You can order suitable cables from SMA. Purchase order numbers: • For outdoor use: COMCAB-OUTxxx* *Available in the lengths xxx = 100 (100 m / 328 ft.);... -
Page 21: Installing The Cable Pipe And Introducing The Cable Into The Inverter
⁄ in. (19 mm). 2. Install the cable pipe on the free opening of the SMA DC-Disconnect. Use matching nuts on the inside to screw the cable pipes to the the SMA DC-Disconnect. 3. If you want to install a fault sensor on the multi-function relay: Install the distribution box on the cable pipe. -
Page 22: Replacing Standard Quick Modules With Rs485 Quick Modules
☑ The cable pipes are installed and the cables are led into the inverter. 5.5 Replacing Standard Quick Modules with RS485-Quick Modules 1. Open SMA DC-Disconnect (see section 5.1 „Open SMA DC-Disconnect.“ (page 19)). 2. Pull the Quick Module downwards to the stopper. -
Page 23: Connecting The Rs485 Cable To The Rs485 Quick Module
Bluetooth communication (see page 15). 7. Close the DC-Disconnect (see section 5.8 „Closing the SMA DC-Disconnect and Commissioning the Inverter“ (page 28)). 5.6 Connecting the RS485 cable to the RS485-Quick Module In this guide it is assumed that the inverter is not connected to an end of the RS485 bus. - Page 24 Assembly SMA America, LLC 3. Slacken the strain relief screw in a counterclockwise direction. 4. Remove the jumper. 5. Remove the filler-plug from the right-hand cable entry. 6. If two cables are to be connected: remove the filler- plug from the left-hand cable entry.
- Page 25 SMA America, LLC Assembly 12. Connect conductors to the connector terminals and note down the color of the wires: Signal RS485-Quick Module Insulated conductor color RS485 bus Data+ Data- 13. Close the spring-type terminals. 14. Push the cable with the shield, stuck to the cable with copper foil, into the shield terminal.
-
Page 26: Multi-Function Relay Connection
Assembly SMA America, LLC 5.7 Multi-function relay connection 5.7.1 Connection Requirements You have the possibility to use an external signal transmitter to display smooth operations as well as errors. You can switch the following voltages and currents. Maximum voltage Maximum current AC source 15 V 1.0 A... - Page 27 SMA America, LLC Assembly Connection plan for fault signaling contact Installation Guide RS485-QM-IA-eng-IUS111610...
-
Page 28: Closing The Sma Dc-Disconnect And Commissioning The Inverter
1. Check the cable routing to ensure that no cable impedes the cover seal and that the cover does not apply pressure to the connections when it is screwed down. 2. Check all of the knockout fittings of the SMA DC-Disconnect and make sure that they provide a weather-tight seal. -
Page 29: Decommissioning And Disposal
Alternatively, send it back to SMA with shipping paid by sender and labeled "ZUR ENTSORGUNG" ("FOR DISPOSAL") (contact: see Page 31). -
Page 30: Technical Data
Technical Data SMA America, LLC 7 Technical Data Communication Communication Interfaces RS485 Maximum RS485 range 3 935 ft. (1 200 m) Environmental conditions in operation Ambient temperature − 13 °F … +131 °F ( − 25 °C … +60 °C) Relative humidity* 5 % …... -
Page 31: Contact
SMA America, LLC Contact 8 Contact If you have technical problems concerning our products, contact the SMA Serviceline. We need the following information in order to provide you with the necessary assistance: • Inverter type • Serial number of inverter • Type and number of modules connected •...
