DIP switch (section1.2.2 #17)
Switch 1 – BOOT_CONFIG(1)

Switch 2 – BOOT_CONFIG(2).

Switch 3 – BOOT_CONFIG(3)

Switch 4 – BOOT_CONFIG(0)


3.18.4 Extra Low Speed Expansion Connector

C865 DEV KIT has 3 extra low-speed expansion connectors. See Section 4 for detail.

3.18.5 Extra High Speed Expansion Connectors

C865 DEV KIT has 3 high-speed expansion connector. See Section 5 for detail
