Understanding The Status Leds - ADTRAN NetVanta 1561i-04 Quick Start Manual

1. Connect a DB-9 to RJ-45 serial cable to the RJ-45 CONSOLE port.
2. Connect the other end of the RJ-45 serial cable to the serial terminal on the PC.
3. Open a VT100 terminal session using the following settings: 115200 baud; 8 data bits; no parity bits; 1 stop bit; and no flow control. Press <Enter> to activate
the CLI.
4. Login with the default user name (admin) and password (password).

Understanding the Status LEDs

The LEDs on the NetVanta 1561i-04 switch's front panel provide you with the ability to monitor the device status. The following section describes the types of LEDs
available on the switch device.
Power Status LEDs
The power status LEDs (Power1 and Power2) indicate if the device is powered up correctly.
LED Color State
Off
P1 Green
On
Off
P2 Green
On
System Status LED
The system status LED indicates whether the system is ready for use.
LED Color State
Off
SYS Green
On
Alarm Status LED
The alarm status LED indicates whether the system is functioning normally.
LED Color State
Off
ALM Red
On
Ring Master (RM) and Rapid Chain (RC) Status LEDs
The RM and RC status LEDs indicate whether the Rapid Ring feature, configured using the DIP switch, is ready for use.
LED Color State
Green On
RM
On
Amber
Off
Green On
On
RC
Amber Blinking
Off
Port Status LEDs
The port status LEDs indicate the current status of each port.
LED Color State
On
Green
Blinking
RJ-45 Ports (1 & 2) On
Amber
Blinking
Off
617111561F1-13A
Description
The device is not receiving power from Power1.
The device is powered ON correctly.
The device is not receiving power from Power2.
The device is powered ON correctly.
Description
The device is not ready for use.
The device is ready for use.
Description
The system is functioning normally.
The system is not functioning normally or an issue has been detected with the device temperature, voltage,
or DC power.
Description
Ring Master has been detected in the device.
Ring Member has been detected in the device.
Ring Master is disabled.
Rapid Chain has been detected in the device (active path).
Rapid Chain has been detected in the device (backup path).
There is no correspondent Rapid Chain device found.
Rapid Chain is disabled.
Description
The port is enabled and a link to the connected device has been established with a speed of 1000 Mbps.
The port is transmitting/receiving packets with a connection speed of 1000 Mbps.
The port is enabled and a link to the connected device has been established with a speed of 10/100 Mbps.
The port is transmitting/receiving packets with a connection speed of 10/100 Mbps.
The cable is not connected to an active port or device, or the port is disabled.
7
