REMOTE CONTROL

1. Control command transmission indicator
2. Auto/Manual button
3. Schock warning button
4. Y-axis tilt button
5. Clockwise Rotation button
6. X-axis tilt button
7. Y-axis tilt button
8. X-axis tilt button
9. Scan Mode
10. Speed button
FEATURES
1. Self-leveling electronic mechanism on slopes of ± 5°
2. 360° rotation generates a horizontal or vertical level plane
3. Generates an inclined plane of any angle in both the X and Y planes
(manual mode)
4. Four variable speeds (0/120/300/600 rpm)
5. Adjustable scan modes create visible laser lines
6. Plumb Up
7. Standard tripod thread (5/8") for vertical or horizontal use, and for
attachment to angle bracket
8. Work-site tough rubber bumpers and ergonomic handle
9. Remote Control and Laser Detector included
10. Remote control and laser detector
11. Setting the inclined plane up to ± 5° along Х and Y axis (manual mode)
POWER SUPPLY FOR:
Laser level
Laser level is supplied with the rechargeable batteries and charger (AC/
DC Converter).
NOTE: Do not use rechargeable batteries and charger simultaneously. it
can damage the tool.
1. Charge the rechargeable batteries if the power indicator blinks (№1 pic.2).
2. Connect the charger to an electrical outlet.
3. Insert the connector into the pin socket (№5 pic.1).
