CALIBRATION
Laser level is calibrated on the factory. Check the calibration any time when
you drop the tool or mishandle it.
6
HORIZONTAL PLANE CALIBRATION TEST
1. Set up the tool approximately 150ft (50m) from a wall or a measuring
staff.
2. Level the instrument as accurately as possible.
3. Position it so that the X-axis is pointing in the direction of the mea-
suring staff or wall.
4. Turn on the tool.
5. Mark the height of the laser beam on the measuring staff or make a
mark on the wall.
6. Rotate the instrument by 180°.
7. Mark the height of the laser beam on the measuring staff or make a
new mark on the wall. The difference between the heights or marks
should not exceed 15 mm.
8. Repeat this procedure for the Y axis.
