Plug in the Activate Station

1. Locate the 24V DC power supply.
2. Connect the AC power cord into the DC power supply.
3. Insert the DC connector into the DC power jack on the back.
4. Plug the AC power cord into an electrical outlet.
5. The white power light on the front of Activate Station will glow.
6. The blue status light will begin blinking as it searches for its paired
classroom audio base station (Redcat, Topcat, 975 or Access Link).
NOTE: If Activate is being added to an existing Lightspeed audio system, please
refer to the Pairing Procedure at www.lightspeed-tek.com/accessregistration.
10
Access
Audio Inputs Audio Outputs Bluetooth Pairing
Pair
1 2
Charge Out (5V USB
Charging Disabled When Aux Power Used
Power
Phone/Pods Pods/Remote
24VDC/1.75A
1.0A 500mA Aux
Power Input
5VDC/0.3A
DC CONNECTOR
24V DC POWER SUPPLY
24V POWER SUPPLY
AC POWER CORD
