The link rate of an interface can be assigned to a desired rate. A network
administrator may want to set the rate manually if autonegotiation fails to
select a rate consistently or if it selects a rate that is slower than the maximum
rate supported by both interfaces.
To set the link rate:
1. In the navigation bar, select System.
2. In the System menu, select Set Link.
3. Select Subscriber Ethernet or Provider Ethernet.
4. Select the appropriate link rate for your Ethernet network (Note: If you
set either 5300-S interfaces to 100FD, be sure you set the device at the
other end of the line to 100FD also.):
Setting
10baseT-HD
10baseT-FD
Configuring Network Settings
Description
10Mbits per second using half duplex
transmission
10Mbits per second using full duplex
transmission
4 - 7
