User Guide V IU 5300-S Series Converged Network Appliance

Features

Front Panel

1 - 4
• Resolves firewall traversal problems at the Network Operations Center for
VoIP by providing a VoIP application layer gateway (ALG) or voice and
video aware firewall that supports SIP, MGCP and H.323
• Resolves firewall traversal problems at customer offices for VoIP by
providing NAT-Traversal capability for SIP.
• Supports up to 500 concurrent VoIP calls or up to 25 Mbps of H.323 video
traffic.
• Protects the enterprise LAN using a stateful packet inspection (SPI)
firewall for both voice and data traffic.
• Performs static IP routing.
• Provides integrated test tools to facilitate problem isolation.
• Performs TFTP relay for IP phone images.
• Uses a simple web based GUI for configuration and management.
• Supports logging to external syslog servers and interfaces to network
management systems using SNMP.
The front panel of the 5300-S has the following ports:
Port
Subscriber (ETH0) Ethernet
Port 1
Provider (ETH1) Ethernet
Port 2
Out of Band Management
Port 3
Console Port
Description
This port is a 10/100 auto sensing port. It
is connected through an Ethernet switch
to IP phones, IADs or PCs installed on the
public network.
This port is a 10/100 auto sensing port. It
is connected to the private network.
This port can be configured to allow out of
band management sessions. It is typically
connected to a private management
network.
This port is used to establish a local
console session with the 5300-S using a
VT100 terminal or emulation program.
The baud rate is 9600. It is used for debug
or local diagnostic purposes only
