Appendix D Modbus

Associated Values for Specific Registry Entries

Device Status
Entries
Device State
Entries (LSByte)
Device SubState
Entries (MSByte)
Data Packet Status
Entries
Page D-8

Table D-5 Associated values for specific registry entries

0x0001 Data Collection
0x0002 Data Available
0x0004 Data Clear
0x0008 Reset
0x0010 Green Status
0x0020 Red Status
0x0040 External Alarm
0x0080 IEEE Float mode
0 Idle
1 Sampling
2 Maintenance
3 Error
0 Idle
1 Idle
2 Idle
0 Sampling
1 Sampling
0 Maintenance
1 Maintenance
0 Error
1 Error
2 Error
0x0001 Laser Good
0x0002 Flow Good
0x0004 Hardware Good
Associated Values for Specific Registry Entries
Matches the common coil settings
n/a
Start pump
Pre-Sample
n/a
Tare
n/a
Calibration
n/a
Leak
Cap Off
