Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world
of unique, creative, and affordable solutions to the vast range of problems that confront video,
audio, presentation, and broadcasting professionals on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better!
Congratulations on purchasing your Kramer
Multi-Format Managed Digital Matrix
technology, is ideal for:
•
Professional display systems requiring video signal routing
•
Broadcast, presentation and production facilities, as well as monitoring in large
duplication systems
•
Rental/staging applications
Throughout this user manual the chassis configuration is shown with 16 DVI inputs and 16
DVI outputs as a representation only.
The following cards are available and may be mixed in the same chassis:
•
UHD-IN2-F16 / UHD-OUT2-F16
(Defining the UHD-IN2-F16 / UHD-OUT2-F16
•
UHDA-IN2-F16 / UHDA-OUT2-F16
(Defining the UHDA-IN2-F16 / UHDA-OUT2-F16
•
HDBT7-IN2-F16 / HDBT7-OUT2-F16
(Defining the HDBT7-IN2-F16 / HDBT7-OUT2-F16
•
DTAxr-IN2-F16 / DTAxr-OUT2-F16
(Defining the DTAxr-IN2-F16 / DTAxr-OUT2-F16
•
HDBT-IN2-F16 / HDBT-OUT2-F16
(Defining the HDBT-IN2-F16 / HDBT-OUT2-F16
•
HH-IN2-F16 / HH-OUT2-F16
(see Defining the HH-IN2-F16 / HH-OUT2-F16
•
HS-OUT2-F16
(Defining the HS-OUT2-F16
•
HAD-IN2-F16 / HAD-OUT2-F16
(Defining the HAD-IN2-F16 / HAD-OUT2-F16
•
HAA-IN2-F16 / HAA-OUT2-F16
(Defining the HAA-IN2-F16 / HAA-OUT2-F16
•
HDCP-IN2-F16 / HDCP-OUT2-F16
(Defining the HDCP-IN2-F16 / HDCP-OUT2-F16
The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
VS-1616DN-EM – Introduction
VS-1616DN-EM 2x2 to 16x16 Modular
Switcher. This product, which incorporates HDMI™
on page 42).
on page 44).
on page 51).
on page 55).
on page 59).
on page 60).
on page 63).
on page 65).
on page 68).
Kramer Electronics Ltd.
on page 48).
