- Page 1 Kramer Electronics, Ltd. Preliminary USER MANUAL Model: VS-169TP 16x9 CAT 5 Matrix Switcher...
-
Page 2: Table Of Contents
Your VS-169TP 16x9 CAT 5 Matrix Switcher Using the IR Transmitter Installing the VS-169TP in a Rack Wiring the CAT 5 LINE IN / LINE OUT RJ-45 Connectors Connecting the VS-169TP 16x9 CAT 5 Matrix Switcher Connecting the RS-232 Ports 6.1.1 Connect the Local RS-232 Ports 6.1.2... - Page 3 Figure 16: MATRIX STATUS Display in the RS-232 (Rx) Breakaway Mode Figure 17: The KFR-Programmer Window Tables Table 1: VS-169TP 16x9 CAT 5 Matrix Switcher Front Panel Functions Table 2: VS-169TP 16x9 CAT 5 Matrix Switcher Rear Panel Functions Table 3: CAT 5 PINOUT...
- Page 4 Contents Table 8: Protocol Definitions Table 9: Instruction Codes for Protocol 2000...
-
Page 5: Introduction
11 groups that are clearly defined by function. Thank you for purchasing the Kramer VS-169TP 16x9 CAT 5 Matrix Switcher. This unique matrix switcher, which utilizes cheap twisted pair cabling often pre- installed in buildings these days, routes and distributes signals both from a local source and at extended ranges (via twisted pair). -
Page 6: Achieving The Best Performance
European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at http://www.kramerelectronics.com/support/recycling/. -
Page 7: Quick Start
Getting Started Quick Start This quick start chart summarizes the basic setup and operation steps. -
Page 8: Overview
Overview Overview The VS-169TP is a high-performance matrix switcher for video signals up to WUXGA/1080p, analog stereo / S/PDIF audio and bidirectional RS-232 signals, over twisted pair CAT 5 cable. The unit can route any input to any or all outputs simultaneously. -
Page 9: Shielded Twisted Pair (Stp) / Unshielded Twisted Pair (Utp)
BC-STP is intended for digital signals and for analog signals where skewing is not an issue. For cases where there is skewing, our UTP skew-free cable, Kramer BC-XTP, may be used. Bear in mind, though, that we advise using STP cables where possible, since the compliance to electromagnetic interference was tested using those cables. -
Page 10: Figure 1: Vs-169Tp 16X9 Cat 5 Matrix Switcher Front Panel
Your VS-169TP 16x9 CAT 5 Matrix Switcher Figure 1: VS-169TP 16x9 CAT 5 Matrix Switcher Front Panel KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 11: Table 1: Vs-169Tp 16X9 Cat 5 Matrix Switcher Front Panel Functions
Your VS-169TP 16x9 CAT 5 Matrix Switcher Table 1: VS-169TP 16x9 CAT 5 Matrix Switcher Front Panel Functions Feature Function IR Receiver/IR LED The red LED is illuminated when receiving signals from the infrared remote control transmitter POWER LED Illuminates green when receiving power... -
Page 12: Figure 2: Vs-169Tp 16X9 Cat 5 Matrix Switcher Rear Panel
Your VS-169TP 16x9 CAT 5 Matrix Switcher Figure 2: VS-169TP 16x9 CAT 5 Matrix Switcher Rear Panel KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 13: Table 2: Vs-169Tp 16X9 Cat 5 Matrix Switcher Rear Panel Functions
2 Covered by a cap. The 3.5mm connector at the end of the internal IR connection cable fits through this opening 3 Optional. Can be used instead of the front panel (built-in) IR receiver to remotely control the VS-169TP (only if the internal... -
Page 14: Using The Ir Transmitter
Gateway: 192.168.1.1 Using the IR Transmitter You can use the RC-IR2 IR transmitter to control the VS-169TP via the built-in IR receiver on the front panel or, instead, via an optional external IR receiver . The external IR receiver can be located 15 meters away from the machine. -
Page 15: Installing The Vs-169Tp In A Rack
Installing the VS-169TP in a Rack Installing the VS-169TP in a Rack This section describes how to install the VS-169TP in a rack. -
Page 16: Wiring The Cat 5 Line In / Line Out Rj-45 Connectors
RS-232 IN 1 and/or the RS-232 IN 2. 1 FTP means Foiled twisted pair 2 Switch OFF the power on each device before connecting it to your VS-169TP. After connecting your VS-169TP, switch on its power and then switch on the power on each device... - Page 17 If necessary, set the H SYNC and V SYNC switches 3. For signal sources that are located at a distance from the VS-169TP, connect the remote transmitters/receivers as follows: Connect up to 16 transmitters (for example, the Kramer ...
-
Page 18: Figure 4: Connecting The Vs-169Tp 16X9 Cat 5 Matrix Switcher
Connecting the VS-169TP 16x9 CAT 5 Matrix Switcher Figure 4: Connecting the VS-169TP 16x9 CAT 5 Matrix Switcher KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 19: Connecting The Rs-232 Ports
To connect a PC or controller to the local ports, connect the 9-pin D-sub ports of the PC or controller to the LOCAL IN RS-232 IN 1 and/or RS-232 IN 2 ports, and to the LOCAL RS-232 OUT port of the VS-169TP unit (via RS-232 cables), as required. -
Page 20: Setting The Machine
Connecting the VS-169TP 16x9 CAT 5 Matrix Switcher 6.2.1 Setting the Machine # To control a unit remotely via RS-232, RS-485, IR or the Ethernet, each unit has to be identified via its unique Machine #. Set the Machine #... -
Page 21: Control The Vs-169Tp 16X9 Cat 5 Matrix Switcher
Table Figure 6: Controlling the VS-169TP via the RS-232 Interface If several Kramer units are connected to one PC, use the daisy chain connection (PC to RS-232 IN, RS-232 OUT to RS-232 IN on the next machine, and so on). -
Page 22: Controlling Via The Rs-485 Interface
Control the VS-169TP 16x9 CAT 5 Matrix Switcher Controlling via the RS-485 Interface To control the VS-169TP unit via the RS-485 interface (see Figure 1. Connect the 9-pin D-sub COM port of the PC to the RS-232 IN 9-pin D- sub F port on the VP-43xl. -
Page 23: Controlling Via The Ethernet
7.3.1 Connecting the ETHERNET Port directly to a PC (Crossover Cable) You can connect the Ethernet port of the VS-169TP to the Ethernet port on your PC, via a crossover cable with RJ-45 connectors. This type of connection is recommended for identification of the factory default... -
Page 24: Connecting The Ethernet Port Via A Network Hub (Straight-Through Cable)
Figure 9: Internet Protocol (TCP/IP) Properties Window 7.3.2 Connecting the ETHERNET Port via a Network Hub (Straight-Through Cable) You can connect the Ethernet port of the VS-169TP to the Ethernet port on a network hub or network router, via a straight-through cable with RJ-45 connectors. -
Page 25: Understanding The Vs-169Tp 16X9 Cat 5 Matrix Switcher
UXGA, analog audio and RS-232 signals. Transmitting the RS-232 Signal The video and audio signals are always transmitted in one direction, when using the VS-169TP, from the source (via the input) to the acceptor (via the output). However, the RS-232 signal behaves entirely differently: •... -
Page 26: Figure 10: Switching An Input To An Output
IN 10, it might be rejected by the control unit since it includes a mix of reply signals, and control of the destination units becomes impossible. To avoid a mixed RS-232 reply command, the VS-169TP passes only one reply from the output back to the input. In the FOLLOW mode, the VS-169TP passes the RS-232 reply from the output which has the lowest numerical value (in this example, OUT 3). -
Page 27: Operating The Vs-169Tp 16X9 Cat 5 Matrix Switcher
Operating the VS-169TP 16x9 CAT 5 Matrix Switcher Figure 12 shows the MATRIX STATUS display in the Follow Mode: Figure 12: MATRIX STATUS Display in the Follow Mode In the breakaway mode, you can select the output port from which the reply... -
Page 28: The Status 7-Segment Display
2. Press an IN button to select the input to switch to the output. The selected input number appears on the 7-segment display. Incomplete operations on the VS-169TP timeout after 25 seconds 9.3.1 Switching one Input to all Outputs To switch one input to all the outputs (in the AT ONCE mode): 1. -
Page 29: Clearing An Output
Operating the VS-169TP 16x9 CAT 5 Matrix Switcher line of the selected signal blinks. 2. Press the appropriate IN button. This input switches to all the outputs, and the MATRIX STATUS display shows the selected input number. To switch one input to all the outputs in the CONFIRM mode (the TAKE button illuminates), do the following: 1. -
Page 30: Confirming Settings
Operating the VS-169TP 16x9 CAT 5 Matrix Switcher 3. Press the TAKE button to confirm the action. All the outputs are cleared. Confirming Settings You can choose to work in the At Once or the Confirm mode. In the At Once mode (TAKE button does not illuminate): •... -
Page 31: Storing/Recalling Input/Output Configurations
The memory recalls the stored data from that reference. Tip: If you cannot remember which of the 15 input configurations is the one that you want, set the VS-169TP to the Confirm mode and manually scan the input/output configurations until you locate it. -
Page 32: Locking The Front Panel
The FOLLOW button and the TAKE button blink 2. Press the TAKE button. 1 Even when the front panel is locked you can still operate via RS-232 or RS-485, as well as via the Kramer RC-IR2 infrared Remote Control Transmitter... -
Page 33: Breakaway Mode Operation
Operating the VS-169TP 16x9 CAT 5 Matrix Switcher 9.7.2 Breakaway Mode Operation To set the VS-169TP to the Breakaway mode: 1. Press one of the BREAKAWAY buttons (UXGA, AUDIO + RS-232 (Tx) or RS-232 (Rx)). The selected button blinks. 2. Press the desired channel a second time. -
Page 34: Figure 15: Operating In The Rs-232 (Rx) Breakaway Mode
Operating the VS-169TP 16x9 CAT 5 Matrix Switcher OUT 3 UXGA AUDIO + RS-232 (Tx) RS-232 (Rx) Blocked IN 10 OUT 5 UXGA AUDIO + RS-232 (Tx) RS-232 (Rx) Blocked OUT 8 UXGA AUDIO + RS-232 (Tx) RS-232 (Rx) Figure 15: Operating in the RS-232 (Rx) Breakaway Mode... -
Page 35: Flash Memory Upgrade
Section 10.1 • Ethernet Firmware (see Section 10.2 10.1 Switcher Firmware Upgrade The VS-169TP uses a microcontroller that runs firmware located in FLASH memory. The latest version of firmware and installation instructions can be downloaded from the Kramer Web site at www.kramerelectronics.com... -
Page 36: Upgrading Firmware
5. Wait until downloading is completed and the red Send button turns off. 6. Disconnect the power on the VS-169TP. 7. Release the ETHERNET FLASH button on the rear panel. 8. Connect the power on your machine. 1 To which the VS-169TP is connected on your PC KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 37: Technical Specifications
Technical Specifications 11 Technical Specifications The VS-169TP technical specifications are shown in Table 6: Table 6: VS-169TP Technical Specifications SIGNAL INPUTS: 16 CAT 5 remote transmitters on RJ-45 connectors 2 local RGBHV UXGA on 15-pin HD connectors 2 local stereo analog audio on 3.5mm mini connectors... -
Page 38: Table 7: Vs-169Tp Hex Table
Hex Table Table 7: VS-169TP Hex Table OUT1 OUT 2 OUT 3 OUT 4 OUT 5 OUT 6 OUT 7 OUT 8 LOCAL IN 1 IN 2 IN 3 IN 4 IN 5 IN 6 IN 7 IN 8 IN 9... -
Page 39: Kramer Protocol 2000
Kramer Protocol 2000 13 Kramer Protocol 2000 The VS-169TP is compatible with Kramer’s Protocol 2000, version 0.51. This RS-232/RS-485 communication protocol uses four bytes of information as defined below. The default data rate is 9600 baud, with no parity, 8 data bits, and 1 stop bit. - Page 40 (127 = load SETUP #) or SETUP # LOAD AUDIO DATA Set equal to audio input Set equal to audio output 22, 23 (0 = disconnect) (0 = to all the outputs) (127 = load SETUP #) or SETUP # KRAMER: SIMPLE CREATIVE TECHNOLOGY...
- Page 41 Kramer Protocol 2000 INSTRUCTION DEFINITION FOR SPECIFIC INSTRUCTION NOTE DESCRIPTION INPUT OUTPUT IDENTIFY MACHINE 1 - video machine name 0 - Request first 4 digits 2 - audio machine name 1 - Request first suffix 3 - video software version...
- Page 42 NOTE 19 – After this instruction is sent, the unit will respond to the ASCII command set defined by the OUTPUT byte. The ASCII command to operate with the HEX command set must be sent in order to return to working with HEX codes. KRAMER: SIMPLE CREATIVE TECHNOLOGY...
- Page 43 Kramer Protocol 2000 NOTE 20 – When data (i.e. the INPUT and/or OUTPUT bytes) of more than 7 bits is required, instruction 63 is sent before sending the instruction needing the additional bits. The data in this instruction then becomes the Most Significant Bits of that next instruction.
- Page 45 For the latest information on our products and a list of Kramer distributors, visit our Web site: www.kramerelectronics.com where updates to this user manual may be found. We welcome your questions, comments and feedback. Safety Warning: Disconnect the unit from the power supply before opening/servicing.
