# Feature
35
OUT 1~8
Connectors
36 OUT 9~16
Connectors
37 Test Module DVI Molex 24-pin
Video Connector
38 Test Module 3.5mm Mini Jack
Unbalanced Analog Audio
Connector
VS-1616DN-EM – Introduction
Function
Connect to the relevant video acceptors, depending on the cards
installed (1 to 8, see
on page 10).
OUTPUTS
Connect to the relevant video acceptors, depending on the cards
installed (9 to 16, see
on page 11).
Connect to one of the relevant video inputs/outputs to aid in
troubleshooting (see
Problems
Connect to one of the relevant audio inputs/outputs to aid in
troubleshooting (see
Problems
Connecting the VS-1616DN-EM
Connecting the VS-1616DN-EM
Troubleshooting Video
on page 89).
Troubleshooting Audio
on page 91).
