Quick VS-1616DN-EM Card Comparison

Card Ports
UHD 2 HDMI
UHDA 2 HDMI
2 Analog audio on
3.5mm mini jacks
HDBT 2 HDBaseT TP on
RJ45 connectors
2 RS-232 Serial and 2 IR
on a 10-pin terminal
block
1 Ethernet on an RJ-45
connector
HDBT7 2 HDBaseT TP on RJ45
connectors
2 RS-232 Serial on a
10-pin terminal block
2 IR ports on 3.5mm
jacks
DTAxr 2 HDBaseT TP on RJ45
connectors
2 RS-232 Serial ports, 2
IR ports, and 2 analog
audio ports on a 16-pin
terminal block
1 Ethernet port on an
RJ45 connector
HH 2 HDMI
HS 2 HDMI
(Out)
UHDS 2 HDMI
HAD 2 HDMI
2 Digital audio on RCA
connectors
HAA 2 HDMI
2 Analog audio on
3.5mm mini jacks
HDCP 2 DVI-D on a DVI Molex
24-pin (F) connector
DGKat 2 TP DGKat on RJ-45
2 Serial on 3-pin
terminal blocks
VS-1616DN-EM – Technical Specifications
BW per Max. Range
Channel
10m (32ft) –
2.97Gbps
4K60 4:2:0 or
4K30 4:4:4
15m (49ft) –
1080p 12 bit
(deep color)
10m (32ft) –
2.97Gbps
4K60 4:2:0 or
4K30 4:4:4
15m (49ft) –
1080p 12 bit
(deep color)
Vid: 2.25Gbps 130m (430ft)
normal mode
Serial: 115200
180m (590ft)
ultra-mode
(1080p@60Hz
@24bpp)*
40m (130ft) – 4K
Vid: 3.4Gbps
@60Hz 4:2:0
Serial: 115200
or 4K @30Hz
4:4:4
70m (230ft) –
1080p 12 bit
(deep color)
100m (330ft) –
Vid: 3.4Gbps
normal mode
Serial: 115200
(4K @60Hz
4:2:0 or 4K
@30Hz 4:4:4)
130m (430ft) –
normal mode
(2K)
180m (590ft) –
ultra-mode
(1080p @60Hz
@24bpp*
2.25Gbps 15m (49ft)
15m (49ft) – 1080p
2.25Gbps
12 bit (deep color)
15m (49ft) – 1080p
2.97Gbps
12 bit (deep color)
2.25Gbps 15m (49ft)
2.25Gbps 15m (49ft)
2.25Gbps 15m (49ft)
90m (300ft) –
Vid: 1.65Gbps
1080p @60Hz*
Serial: 19200
Kramer Electronics Ltd.
Compliance 3D
Pass
Thru
HDCP 1.4, HDTV Yes
compatible
HDCP 1.4, HDTV Yes
compatible
HDCP 1.4, Yes
HDBaseT
HDCP 1.4, Yes
HDBaseT, HDTV
compatible
HDCP 1.4, Yes
HDBaseT, HDTV
compatible
HDCP 1.4 Yes
HDCP 1.4, HDTV No
compatible
HDCP 1.4, HDTV
compatible
HDCP 1.4 Yes
HDCP 1.4 Yes
HDCP, HDMI Yes
HDCP 1.4, HDMI Yes
