BVM PNP F-16 Assembly And Operating Manual page 25

 Using a long bit, dill 1/16 holes through
the Bypass and into the forward former
on both sides to except #2x5/8" BHCS.
 Using a long bit, dill 1/16 holes through
the Bypass and into the aft former on
both sides to except #2x5/8" BHCS.
 Mark an opening for the wires about
1.25"x.7" in front of the fwd former 2.25'
below the turbine rail. Make this
clearance hole for electrical connections
as necessary. Route the wires forward
to the E.C.U.
 Remove the front socket head cap
screws using a 2.5mm hex wrench on
both stock turbine rails.
BVM ®2016 24 4/12/2019
