Repeat the above steps to assemble the structure on the other side.
Use M4*40 screws to pass through these from top to bottom: MF84ZZ bearing
(small), aluminum alloy (long large hole), aluminum alloy (small hole), aluminum
alloy (small hole), aluminum alloy (long large hole) , MF84ZZ bearing (small), M4
nut. As shown below.
