Mounting, demounting and electric installation
IRQ (Interrupt) conflict with other PC hardware components of the control
●
cabinet PC
The software of the card was not installed
●
10.1.6 BIOS settings
No further settings have to be made in the BIOS setup. The corresponding
settings have already been set for the normal operation.
10.2 Housing dimensions
The control cabinet PC can be mounted using mounting holes. For the
corresponding dimensions, please refer to the following figures:
Fix the devices with M5 screws.
