IndraControl VPB 40.4
PC box Type P
Max. Power 150 W
consumption
Weight Approx. 2.6 kg
Tab. 7-1: Technical data of the PC box
The specified maximum power consumption includes the power consumption of
the extension cards, refer to
on page 19.
For details on the individual variants, refer to the type code
of the control cabinet PC IndraControl VPB 40.4" on page

8 Standards

The system components of the control cabinet PC IndraControl VPB 40.4
correspond to the following standards:
Standard
IEC 60204-1
IEC 61010-2-201
IEC 61131-2
ISO 13850
IEC 60529
IEC 60068-2-6
IEC 60068-2-27
IEC 60721-3-1
DOK-MLC***-INDRACTRLV4-IT02-EN-P
chapter 9.9.2 "Power drain of the extension cards"
Title
Safety of machinery –
Electrical equipment of machines –
Part 1: General requirements
Insulation coordination for equipment within low-voltage –
Part 1: Principles, requirements and tests
Programmable controllers –
Part 2: Equipment requirements and tests
Safety of machinery –
Emergency stop – Principles for design
Degrees of protection provided by enclosures (IP code)
Environmental testing –
Part 2-6: Tests –
Test Fc: Vibration (sinusoidal)
Environmental testing –
Part 2-27: Tests –
Test Ea and guidance: Shock
Classification of environmental conditions
Part 3: Classification of groups of environmental parameters and their
severities
Section 1: Storage
Bosch Rexroth AG
Type R
Approx. 3.3 kg
(fig. 15-1 "Type code
79).
Standards
