IndraControl VPB 40.4
Pin Labeling
1 +
2 –
3 U
NOTICE
Ensure that the polarity at the X10 plug and the dimensioning of the fuse are
correct.
WARNING
The 24 V DC input voltage must comply with the requirements of the "safe
separation"!
Plug and remove the plug connection only if there is no voltage!
Conductors
Conductor cross-section inflexible, max.
Conductor cross-section inflexible, recommended
Conductor cross-section flexible, max.
Conductor cross-section flexible, recommended
Conductor cross-section flexible with core end sleeves without plastic sleeve,
max.
Conductor cross-section flexible with core end sleeves without plastic sleeve,
recommended
Conductor cross-section flexible with core end sleeves with plastic sleeve, max.
Conductor cross-section flexible with core end sleeves with plastic sleeve,
recommended
Conductor cross-section AWG/kcmil, max.
Conductor cross-section AWG/kcmil, recommended
Tab. 9-1: Conductor cross-sections permitted for the spring terminal at X10

9.3 Reset button

When the "Reset" button is pressed, the mainboard is restarted immediately.
DOK-MLC***-INDRACTRLV4-IT02-EN-P
Function
Supply voltage 24 V
0 V supply voltage
Supply voltage available in front of the UPS (see
"Connecting a UPS" on page
Destruction of the control cabinet PC (fire
hazard) due
connection at the X10 plug without additional
external protection
Danger without safe separation!
Bosch Rexroth AG
chapter 10.3.2
33)
to polarity reversal
Cross-section
10 mm
2.5 mm
6 mm
2.5 mm
6 mm
2.5 mm
4 mm
2.5 mm
8
13
Interfaces
of the
2
2
2
2
2
2
2
2
15/87
